Features of side intake :
●Water intake from all sides enables the water intake from entire layer
of aquifer and stable intake even at the drawdown in drought.
Features of stainless screen :
●Large opening ratio
●V-shaped opening resists against clogging
●Provide flexible design to suit the aquifer
●Effective water intake from all layers of aquifer.
●Drawdown level is low, even at high water intake volume.
●Allows high-pressure washing from inside
●Flexible in design & selection of slot size and SUS304 gives high
resistance against corrosion
●Opening area ratio: 30-50%
●Water inflow velocity: Slow, less than 1.0cm/sec.
●Less likely to clog
RINGBASE RADIAL WELL SCREEN for SHALLOW WELL
Features of Radial Water Collection Well :
●Enlarging well diameter
●Appropriate positioning by horizontal-boring
Features of Ringbase Radial Well Screen :
●Large opening ratio
●V-shaped opening resists against clogging
●Provide flexible design to suit the aquifer
Radial screen enlarges well radius :
●Water intake volume: 3,000-20,000m3/day
●Smaller head loss gives less drawdown in water level and provides efficient and stable water intake.
●Less clogging and less corrosion leads to long life span.
●Effective water intake from all layers of aquifer even at drawdown of water level in draught condition.
●Collection area: quite large
●Opening ratio: 52%
●Water inflow velocity: Slow, less than 1.0cm/sec
●Flexibility of slot size allows stable and reliable water intake from aquifer.
●Appropriate positioning by horizontal-boring
